Over the years we tested a lot of E Bikes but there was never any bike that truly stole our team’s heart. It took us a while to figure out what kind of bike we want to make for NS. We ask ourselves what makes an e-bikes great Well, if we put the motor on the side for a moment, it all comes down to the bike’s geometry and suspension, and these are the main points that we focused on. We looked for a geometry that works best on a motor assisted bike – and that’s one that is not necessarily the same as on our “analog” products. The geometry must be complemented by suspension that works perfectly on a bike that is inherently heavier than a normal MTB, and the tires, brakes and cockpit all need to have more of a “moto” character.
Back to the motor: there are no “bad” drive units on the market these days. What we think is critical for our customers is reliability and easily accessible service if something goes wrong. That’s why we chose to work with the Shimano. We believe that they have similar values as we do and excellent customer service all over the world. Although it’s been around for a while, we really like the E7000 motor from Shimano. We are not alone in this opinion. In the words of E Mountain bike magazine: “We were immediately impressed with the superb natural ride-experience the Shimano STEPS E7000 provides! Shimano’s “small” drive delivers power inconspicuously, but still offers the level of support you need from a standstill, climbs and when cruising just below the 25 km/h threshold. In direct comparison with its bigger brother the Shimano STEPS E7000 feels more natural. It is also quieter and easier to modulate, especially in Boost mode.”
One of the key things we noticed is that the NS crew doesn’t dig wimpy rides. So, we made sure that the E-Fine is a big, burly machine. It’s fitted with the excellent SRAM 35 Gold RL fork, a coil shock nd aggressive tires. Also, to make sure everyone could feel comfortable on the E-Fine we included an option to adjust the heigh of the BB to suit personal preferences.
So, have we succeeded in making an E Bike that all the guys in our team would love? Well, even the most die-hard dirt jumpers in our company are lining up to borrow a prototype for a weekend of shredding – something that we haven’t seen previously with other E Bikes that have been laying around in the office. Our team riders love the E Fine, our close friends who would never consider going electric are changing their minds. Honestly, we believe we have achieved our goal.
FEATURES:
- Tough alloy frame with double pass welds
- Shimano Steps E7000 system
- 504WH integrated Shimano battery
- Progressive geometry with 44 mm fork rake
- 160 front / 150 rear travel
- ROCK SHOX front suspension (35 Gold RL FORK)
- X-FUSION h3c coil shock
- X-FUSION MANIC
- Shimano Deore 1x11 drivetrain
- Reliable Shimano Deore MT420 BRAKES
- Schwalbe Big Betty tires
SPECS:
| Frame |
NS Bikes E-fine AL w/ 150mm travel, AL6061-T6 + AL6066-T6, custom hydroformed tubes, Shimano Steps E7000 system 504WH integrated Shimano battery |
| Fork |
Rock Shox 35 GOLD RL CROWN ADJUST 29, DEBONAIR 160MM travel E-MTB ,15x110mm Boost, 1.5 tapered steerer tube, 44mm offset |
| Rear Shock |
X-FUSION H3C Trunnion 205x62,5, spring: 350 lbs/in / Marzocchi Bomber CR Trunnion 205x62,5, spring: 350 lbs/in |
| Rims/Wheels |
Octane One Solar 29” front, Octane One Solar 27.5” rear, 32h, tubeless ready |
| Hubs |
NS Bikes Boost (sealed bearings) |
| Spokes |
Spokes w/14mm nipples |
| Tires |
Schwalbe Big Betty BikePark 29x2.4" / Schwalbe big betty BikePark 27.5x2.4" |
| Crankset |
Shimano FC-E8000, 165mm, 38t |
| Chain |
KMC e11 Silver , 11spd |
| Front Derailleur |
N/A |
| Rear Derailleur |
Shimano Deore RD-M5100, 11spd |
|
|
Sun Race CSMS7 , 11-46t, 11spd |
| Shifters |
Shimano Deore SL-M5100-R, 11spd |
| Handlebars |
NS Bikes 800mm, 38mm rise, 35 |
| Stem |
NS Bikes Quantum Lite 45mm, 35 |
| Brake Levers |
Shimano Deore MT420 |
| Brakes |
Shimano Deore MT420 4 piston, 203mm |
| Pedals |
N/A |
| Saddle |
WTB Volt Medium Steel SL |
| Seat Post |
X-Fusion Manic internal S:125, M:150, L: 170mm, 31,6mm / KS Rage-i * |
| Motor |
Shimano Steps E7000, 60nm of Torque |
| Battery |
504WH integrated Shimano battery
|
|
|
SHIMANO STEPS E5000 |
|
|
20 mph (Class 1) |
| Charger |
Included |
|
|
N/A |
