| Sizes |
27.5": XS, S |
| Colors |
Milky Way, Purple Ash |
| Frame |
ALUXX-Grade Aluminum, 120mm FlexPoint Suspension |
| Fork |
Giant Crest 34 RCL, 130mm, 15x110 |
| Shock |
Suntour Raidon R, 184.15/44.45 |
| Handlebar |
Giant Connect Trail, alloy For 27.5: XS:730mm, S:750mm For 29: S:750mm, M:750mm, L:780mm |
| Grips |
Giant Sole-O |
| Stem |
Giant Contact For 27.5: XS:40mm, S:50mm For 29: S:50mm, M:50mm, L:60mm |
| Seatpost |
Giant Contact Switch dropper, remote For 27.5: XS: 75mm travel / 30.9 x 295mm S: 100mm travel / 30.9 x 345mm For 29: S: 100mm travel / 30.9 x 345mm M: 125mm travel / 30.9 x 395mm L: 125mm travel / 30.9 x 395mm |
| Saddle |
Liv Sylvia |
| Pedals |
Sold separately |
| Shifters |
Shimano Deore M4100, 1x10 |
| Front Derailleur |
N/A |
| Rear Derailleur |
Shimano Deore M5120 |
| Brakes |
Tektro HD M745 |
| Brake Levers |
Tektro HD M745 |
| Cassette |
Shimano Deore M4100, 11x46 |
| Chain |
KMC X-10 |
| Crankset |
Praxis Cadet Boost, 30t For 27.5: XS:165mm, S:170mm For 29: S:170mm, M:170mm, L:170m |
| Bottom Bracket |
Praxis, press fit |
| Rims |
For 27.5: Giant AM 27.5, tubeless ready, sleeve-joint rim, 30mm inner width For 29: Giant AM 29, tubeless ready, sleeve-joint rim, 30mm inner width |
| Hubs |
alloy, loose ball |
| Spokes |
Sapim |
| Tires |
For 27.5: [F] Maxxis Rekon 27.5x2.6 WT, EXO, TR, tubeless [R] Maxxis Ardent Race 27.5x2.6 WT, EXO, TR, tubeless |
| Extras |
For 27.5: tubeless prepared, max tire size 2.6", max chainring size 32t |
| Weight |
The most accurate way to determine any bike’s weight is to have your local Bicycle Warehouse weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
