Are you ready to take on any terrain? The Revolt Advanced 0 Gravel Road Bike is here to help you do just that! Whether you're facing rough roads, gravel, or dirt, this bike is ready to roll. With its lightweight composite frame and adjustable wheelbase, you'll be more capable than ever before.
The 2023 model is faster and lighter than ever thanks to its advanced composite frame and fork that saves over 160 grams compared to previous models. Plus, with updated geometry that includes a lower bottom bracket, longer reach, and steeper head tube angle, you'll experience improved acceleration and climbing power.
And let's not forget about the tuned compliance! The dropped seatstays with thin tubing absorb road shocks and vibrations, while the D-Fuse handlebar and seatpost work together to add compliance without sacrificing stiffness when cornering, sprinting, or climbing.
But here's the real kicker - this bike is adaptable to any terrain! The flip chip on the rear dropout lets you adjust the wheelbase for quicker handling or improved stability at speed. And with the long setting, you can even use larger diameter tires up to 53mm! Plus, you can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post to suit your riding style.
So what are you waiting for? Get ready to tackle any road, any gravel, any dirt - and do it with style on the Revolt Advanced 0 Gravel Road Bike!
Fast and light
Advanced composite frame and fork save more than 160 grams compared to previous model. Updated geometry includes a lower bottom bracket, longer reach and steeper head tube angle for improved acceleration and climbing.
Tuned compliance
Dropped seatstays with thin tubing absorbs road shocks and vibrations. D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.
Adaptable to the terrain
A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling, or long for improved stability at speed. The long setting allows for larger diameter tires up to 53mm. You can also choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post
Specifications
Sizes
|
Sizes
|
XS, S, M, M/L, L, XL
|
|
Colors
|
Charcoal Plum, Helios Orange
|
|
Frame
|
Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout
|
|
Fork
|
Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
|
|
Shock
|
N/A
|
|
Handlebar
|
Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
|
|
Grips
|
Stratus Lite 3.0
|
|
Stem
|
Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
|
|
Seatpost
|
Giant D-Fuse, composite, 14mm offset
|
|
Saddle
|
Giant Approach
|
|
Pedals
|
Sold separately |
|
|
Shifters
|
Shimano GRX RX-810, 2x11
|
|
Front Derailleur
|
Shimano GRX RX-810
|
|
Rear Derailleur
|
Shimano GRX RX-810
|
|
Brakes
|
Shimano GRX RX-810 hydraulic, Shimano SM-RT70 rotors [F]160mm, [R]160mm
|
|
Brake Levers
|
Shimano GRX RX-810 hydraulic
|
|
Cassette
|
Shimano CS-HG800, 11-speed, 11x34
|
|
Chain
|
KMC X11SL-1
|
|
Crankset
|
Shimano GRX RX-810, 31/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
|
|
Bottom Bracket
|
Shimano, press fit
|
|
Rims
|
Giant CXR 2 Carbon Disc WheelSystem, [F] 35mm, [R] 35mm
|
|
Hubs
|
[F] Giant alloy, CenterLock, 12mm thru-axle, [R] Giant alloy, 3-pawl driver, CenterLock, 12mm thru-axle
|
|
Spokes
|
Sapim Sprint
|
|
Tires
|
CADEX AR, 700x40c, tubeless
|
|
Extras
|
tubeless prepared, 53mm max tire size in "long" flip chip position, 45mm max tire size in "short" flip chip position
|
|
Weight
|
The most accurate way to determine any bike’s weight is to have your local Bicycle Warehouse weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
|
Geometry
| |
|
XS |
S |
M |
ML |
L |
XL |
| |
|
SHORT | LONG
|
SHORT | LONG
|
SHORT | LONG
|
SHORT | LONG
|
SHORT | LONG
|
SHORT | LONG
|
| A |
SEAT TUBE LENGTH (inch)
|
16.9 |
17.7 |
18.5 |
19.3 |
20.1 |
20.9 |
| B |
SEAT TUBE ANGLE |
74.0° |
73.5° |
73.5° |
73.0° |
73.0° |
73.0° |
| C |
TOP TUBE LENGTH (inch)
|
21.3 |
21.7 |
22 |
22.6 |
23 |
23.6 |
| D |
HEAD TUBE LENGTH (inch)
|
4.9 |
5.3 |
5.9 |
6.5 |
7.1 |
7.7 |
| E |
HEAD TUBE ANGLE |
70.0° |
71.0° |
71.5° |
72.0° |
72.0° |
72.0° |
| F |
FORK RAKE (inch)
|
2 |
2 |
2 |
2 |
2 |
2 |
| G |
TRAIL (inch)
|
3.1 | 3.2
|
2.8 | 3
|
2.7 | 2.8
|
2.6 | 2.7
|
2.6 | 2.7
|
2.6 | 2.7
|
| H |
WHEELBASE (inch)
|
40.5 | 40.9
|
40.4 | 40.7
|
40.6 | 40.9
|
40.7 | 41.1
|
41.1 | 41.5
|
41.8 | 42.2
|
| I |
CHAIN STAY LENGTH (inch)
|
16.9 | 17.3
|
16.9 | 17.3
|
16.9 | 17.3
|
16.9 | 17.3
|
16.9 | 17.3
|
16.9 | 17.3
|
| J |
BOTTOM BRACKET DROP (inch)
|
3.1 | 3.2
|
3.1 | 3.2
|
3.1 | 3.2
|
3.1 | 3.2
|
3.1 | 3.2
|
3.1 | 3.2
|
| K |
STACK (inch)
|
21.9 |
22.4 |
23.1 |
23.7 |
24.3 |
24.8 |
| L |
REACH (inch)
|
15 |
15 |
15.2 |
15.4 |
15.6 |
16 |
| M |
STAND OVER HEIGHT (inch)
|
28.2 | 28.5
|
28.9 | 29.2
|
29.6 | 29.9
|
30.3 | 30.6
|
30.9 | 31.2
|
31.5 | 31.9
|
| N |
HANDLEBAR WIDTH (inch)
|
16.5 |
16.5 |
17.3 |
17.3 |
18.1 |
18.1 |
| O |
STEM LENGTH (inch)
|
2 |
2.4 |
2.8 |
3.1 |
3.1 |
3.5 |
| P |
CRANK LENGTH (inch)
|
6.7 |
6.7 |
6.8 |
6.8 |
6.9 |
6.9 |
| Q |
WHEEL SIZE
|
700x 42C | 50C |
700x 42C | 50C |
700x 42C | 50C |
700x 42C | 50C |
700x 42C | 50C |
700x 42C | 50C |
