Motor
|
SyncDrive Pro, 85Nm, powered by Yamaha
|
|
Controller
|
RideControl Dash
|
|
Display
|
RideControl Dash, full color lcd screen
|
|
Battery
|
EnergyPak Smart 800, EnergyPak Plus 250Wh range extender compatible
|
|
Sizes
|
S, M, L, XL
|
|
Colors
|
Cordovan
|
|
Frame
|
ALUXX SL-grade aluminum, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
|
|
Fork
|
RockShox 35 Silver, 140mm, 1.8" tapered steerer, 110x15 Maxle Stealth
|
|
Shock
|
SR Suntour Raidon R, 190x45mm, custom tuned
|
|
Handlebar
|
Giant Connect TR Riser 31.8x780mm
|
|
Grips
|
Giant Tactal single lock-on
|
|
Stem
|
Giant Contact
|
|
Seatpost
|
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
|
|
Saddle
|
Giant Sport
|
|
Pedals
|
Flat pedal
|
|
Shifters
|
Shimano Deore
|
|
Rear Derailleur
|
Shimano Deore 12-speed
|
|
Brakes
|
Tektro HD-M750 Orion, 4-piston, hydraulic disc, 203mm
|
|
Brake Levers
|
Tektro HD-M750
|
|
Cassette
|
Shimano CS-M6100-12, 10-51T, 12-speed
|
|
Chain
|
KMC e.12 Turbo, EcoProteq, e-bike optimized
|
|
Crankset
|
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
|
|
Bottom Bracket
|
n/a
|
|
Rims
|
Giant AM 29", Tubeless ready, 30mm inner width
|
|
Hubs
|
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
|
|
Spokes
|
Sapim E-Lite [R] Race [F], e-bike optimized
|
|
Tires
|
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 29X2.40" Foldable, WT, TLR, EXO, 60TPI [R]
|
|
Extras
|
Tubeless kit (liquid, valves, levers, manual, tool)
|
|
Lighting
|
-
|
|
Lock
|
Torx 25 Battery Lock with built-in Torque limiter
|
|
Carrier
|
-
|
|
Weight
|
The most accurate way to determine any bike’s weight is to have your local Bicycle Warehouse weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
|
