Get ready to take your gravel riding to the next level with the TCX Advanced Pro 2 Gravel Road Bike! This bad boy is all about fast starts, tight corners, and a blur of speed through dirt, sand, and mud. Used and proven by elite cyclocross pros for years, this latest version of the TCX Advanced Pro is built to win.
The superlight composite frame is handcrafted with race-proven geometry and asymmetrical chainstays for optimal power transfer. And if that's not enough, the D-Fuse composite seatpost helps smooth out bumps and vibrations, making for a more comfortable ride.
Plus, you have the option to use a 30.9mm round standard or dropper seatpost for maximum versatility. With a lightweight composite WheelSystem and tubeless tires right out of the box, you'll be shredding the trails in no time. And with flat-mount disc brakes and 12mm front and rear thru-axles, you'll have total control and fast cornering, sprinting, and climbing in all conditions. So go ahead, unleash your inner pro and conquer those gravel roads like a boss!
Elite level efficiency
Advanced-grade composite frameset is 17.5 percent lighter than the previous generation while retaining its best-in-class torsional/pedaling stiffness.
Total control
Integrated disc brake technology with flat mounts and thru-axle hubs, combined with tubeless ready Giant WheelSystem, delivers added control in variable conditions and all types of weather.
Smooth ride quality
D-Fuse composite seatpost helps absorb bumps and vibrations, and you also have the option to switch to a standard 30.9mm round or dropper post depending on your riding style and terrain.
Specifications
|
Sizes
|
XS, S, M, M/L, L, XL
|
|
Colors
|
Amber Glow
|
|
Frame
|
Advanced-Grade Composite, 12mm thru-axle, disc
|
|
Fork
|
Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc
|
|
Shock
|
N/A
|
|
Handlebar
|
Giant Contact SL XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
|
|
Grips
|
Stratus Lite 3.0
|
|
Stem
|
Giant Contact SL XS:70mm, S:80mm, M:90mm, M/L:100mm, L:100mm, XL:110mm
|
|
Seatpost
|
Giant D-Fuse SL, composite, 16mm offset
|
|
Saddle
|
Giant Approach
|
|
Pedals
|
no pedal [GA, Pan-Eu] platform pedal [GU, GV, GJ] pedal w/toeclip and strap [All other GSC]
|
|
Shifters
|
Shimano GRX RX-600, 1x11
|
|
Front Derailleur
|
N/A
|
|
Rear Derailleur
|
Shimano GRX RX-812
|
|
Brakes
|
Shimano GRX RX-400 hydraulic, Giant MPH rotors [F]160mm, [R]140mm
|
|
Brake Levers
|
Shimano GRX RX-600 hydraulic
|
|
Cassette
|
Shimano CS-M7000, 11-speed, 11x40
|
|
Chain
|
KMC X11
|
|
Crankset
|
Shimano GRX RX-600, 40t XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
|
|
Bottom Bracket
|
Shimano, press fit
|
|
Rims
|
Giant P-X2 Disc wheelset
|
|
Hubs
|
Giant P-X2 Disc wheelset
|
|
Spokes
|
Giant P-X2 Disc wheelset
|
|
Tires
|
Maxxis All-Terrene, 700x33c, tubeless
|
|
Extras
|
Giant 1x chainguide, tubeless prepared, 45mm max tire size
|
|
Weight
|
The most accurate way to determine any bike’s weight is to have your local Bicycle Warehouse weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
|
Geometry
| |
|
S |
M |
ML |
L |
XL |
| A |
SEAT TUBE LENGTH (inch)
|
19.9 |
20.7 |
21.5 |
21.9 |
22.2 |
| B |
SEAT TUBE ANGLE |
73.5° |
73.0° |
73.0° |
73.0° |
73.0° |
| C |
TOP TUBE LENGTH (inch)
|
20.9 |
21.5 |
22 |
22.6 |
23.2 |
| D |
HEAD TUBE LENGTH (inch)
|
5.2 |
5.8 |
6.4 |
7 |
7.6 |
| E |
HEAD TUBE ANGLE |
71.0° |
71.5° |
72.0° |
72.5° |
72.5° |
| F |
FORK RAKE (inch)
|
2 |
2 |
2 |
2 |
2 |
| G |
TRAIL (inch)
|
2.7 |
2.6 |
2.4 |
2.3 |
2.3 |
| H |
WHEELBASE (inch)
|
39.9 |
40.2 |
40.6 |
40.9 |
41.5 |
| I |
CHAIN STAY LENGTH (inch)
|
16.9 |
16.9 |
16.9 |
16.9 |
16.9 |
| J |
BOTTOM BRACKET DROP (inch)
|
2.4 |
2.4 |
2.4 |
2.4 |
2.4 |
| K |
STACK (inch)
|
20.7 |
21.9 |
22.5 |
23.2 |
23.7 |
| L |
REACH (inch)
|
14.6 |
14.8 |
15.2 |
15.6 |
16 |
| M |
STAND OVER HEIGHT (inch)
|
31 |
31.8 |
32.5 |
32.8 |
33.3 |
| N |
HANDLEBAR WIDTH (inch)
|
15.7 |
16.5 |
16.5 |
17.3 |
17.3 |
| O |
STEM LENGTH (inch)
|
3.1 |
3.5 |
3.9 |
3.9 |
4.3 |
| P |
CRANK LENGTH (inch)
|
6.7 |
6.8 |
6.8 |
6.9 |
6.9 |
| Q |
WHEEL SIZE
|
700C |
700C |
700C |
700C |
700C |
