| Frame |
ALUXX SL-Grade Aluminum, Advanced Forged Composite linkage, 140mm Maestro Suspension System, 'Boost' 148x12 UDH derrailleur hanger, Giant EnergyPak Plus Range Extender Compatible
|
| Fork |
Fox 36 Float Rhythm, 150mm travel, 44mm offset, EVOL, Grip Damper, Sweep adjust, Boost 110x15QR, e-optimized
|
| Rear Shock |
Fox Float DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
|
| Rims/Wheels |
Giant AM 29", Tubeless ready, 30mm inner width
|
| Hubs |
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
|
| Spokes |
Sapim E-Lite [R] Race [F]
|
| Tires |
Maxxis Assegai 29x2.6" foldable, Tubeless, EXO [F]Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+ [R]
|
| Crankset |
Praxis Wavetm Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (Q-factor=168, S:160, M/L:165, XL:170)
|
| Chainrings |
36T |
| Bottom Bracket |
N/A |
| Chain |
KMC e.12 Turbo, EcoProteq, e-bike optimized
|
| Front Derailleur |
MRP HD2 co-moulded chain guide
|
| Rear Derailleur |
Shimano Deore XT, 12-speed, Shadow+
|
| Cassette/Rear Cogs |
Shimano CS-M6100-12, 10-51T, 12-speed
|
| Shifters |
Shimano SLX |
| Handlebars |
Giant Contact 35 Trail, 35x780mm
|
| Grips |
Giant Tactal Pro-E, single lock-on
|
| Stem |
|
| Brakes |
Shimano Deore BR-M6120, 4-piston, hydraulic disc, 203mm
|
| Pedals |
N/A |
| Saddle |
|
| Seat Post |
Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)
|
| Motor |
SyncDrive Pro, 85Nm, powered by Yamaha
|
| Battery |
EnergyPak Smart 625Wh, EnergyPak Plus range extender compatible
|
| Display/Controller |
RideControl GO, frame integrated LED displayANT+ Wireless display compatible w/ RideControl Ergo 3, grip integrated
|
| Max Assisted Speed |
20mph (Class 1) |
| Accessories & Extras |
Tubeless kit (liquid, valves, levers, manual, tool)
|
